Labels and symbols
The main label for the lifter is placed on the chas-
sis behind the column
On the left side of the column
there is a short guide.
Explanation of symbols used in this manual
This symbol is used to point out instructions
and information related to work place safety
where injury may occur if the information is
disregarded or ignored. Follow these instruc-
tions, be careful and attentive at all times.
This symbol indicates important and useful
information. If taken into consideration, it
will help the operator of the lifter to work ef-
ficiently. It may help simplify routines and to
explain complicated facts.
Manufacturer
Read user manual!
SWL, maximum
load
Indoor use
only
Model name
CE mark
Serial number as
bar code / number
Nominal battery voltage
and protection class
Type BF Applied part
(IEC 60601)
Part number
Separate waste
collection
CSA tested
and approved
The safety control label is also placed on chassis
behind the column.
Read user manual!
Check that lifter has no
damage or faults before use
(checklist before use)
Place user in upright
position
Position with near 90° in
ankles and knees
Attachment of sling on
U-shaped arm
Attachment of sling on
V-shaped arm
Lifting the user carefully,
user leaning backwards
This label has desig-
nated space for the
calendar and signed
label that the service
partners attach to the
lifter when periodic in-
spection is performed
Control the lifter each
12 month according
to list for periodic in-
spection on page 18
Read user manual
