ETC Setup Guide
Eos Rackmount Devices
Eos Rackmount Devices Page 5 of 12 ETC
Eos Remote Interface
The Eos Remote Interface is a rackmount device designed to offer remote video and programming
functions for Eos Family control systems. INLINESNIPPET. The Eos Remote Interface supports up to
three external 4K monitors, with optional multi-touch via USB.
The Remote Interface ships with the following:
•
One three-button scroll mouse and mousepad
•
Alpha-numeric keyboard
•
Locking regionalized IEC power cord
•
Two 19-inch rack-mount ears and mounting hardware
•
Four rubberized feet (for desktop use)
•
Augment3d AR target kit
Hardware Setup
Note: For information on mounting the Remote Interface in a rack, see Rack Mounting.
1
2
3
4
5
6
1. Hard power switch
2. IECpower connector
3. USB-A &USB-C (data)
4. Display Port
5. Ethernet
6. Audio ports (not currently enabled)
