Cleaning Lens and Reflector 11
Cleaning the reflector
To quickly clean the reflector, remove the lens tube and clean the dust from the reflector with a blast
of oil-free air. You may also wipe the reflector with a clean lint-free cloth. If either method is not
sufficient, follow these steps.
Step 1: To protect the lamp housing during cleaning, remove the lamp housing by loosening the
knurled bolt and pulling the housing straight out. See Figure 3.
Step 1: Remove the barrel rotation knob located at the bottom of the barrel (see Figure 1). Use
a Phillips screwdriver to remove the retainer bolt located on top of the reflector housing.
Step 2: Rotate the barrel 45° in either direction. Carefully remove the barrel from the reflector
housing.
Step 3: Remove dust with a blast of oil-free air or wipe with a clean, lint-free cloth. Isopropyl
alcohol, distilled water or a 50%-50% mixture of each can be used to clean the glass
surface.
Step 4: Gently wipe the reflector.
Step 5: Insert the barrel into the reflector housing with the iris/pattern slot on top. Align the
triangles on both parts.
Step 6: While gently pressing in, rotate the barrel 45° clockwise until it sets into position, then
rotate the barrel counterclockwise 45°. The barrel should be firmly attached and the
triangles should be aligned.
Step 7: Reinstall the barrel rotation knob and tighten the retainer bolt.
Step 1: Reinstall the lamp housing and tighten the knurled bolt.
WARNING:
Unplug the fixture before attempting to clean the reflector.
