ETC Source Four Zoom - Basic Assembly

Basic Assembly 1
Basic Assembly
WARNING:
Please note the following safety warnings before use:
Do not mount the fixture on or near combustible surfaces.
Do not operate the fixture without a lens installed.
Always hang the fixture with the color frame retaining clip in the locked
position.
Remove cardboard insert from lens tube before connecting power to your
fixture.
Figure 1
Lamp housing
Insulated handle
Reflector housing
Yoke
Pattern holder slot
Drop-in iris slot
Shutters
Color frame
Barrel
25°-50° lens tube
Barrel rotation knob
Focus dial
Color frame
retaining gel clip
15°-30° lens tube
Optional
Balancing yoke
Retainer bolt
Yoke locking knob
