27
Figure 4-4connection for the Ventilator
4.3 Connect tube
Figure 4-5 connection for patient tubing
You can connect the patient tubing as figure 4-5, and then connect it with ventilator.
Figure 4-6 Attaching a Nebulizer
You can use an in-line nebulizer with the Vela ventilator. To use a nebulizer you must have a
high-pressure oxygen source attached to the ventilator. Attach the nebulizer tubing as shown in
figure 4-6.
4.4 Connecting Gas and Electricity
Warning：
Put the power cord and screwed tube in a certain place, to avoid apnea the patient.
Only connect external power adapter with ISO-standard socket. And pay attention to polarity if
