Remote control (ES-RC1N)
Design
Connection to your alarm system
The remote controls in your kit are already connected and ready to use. If you have
deleted a remote control from the control panel, you can reconnect it as follows:
1. Press once on the Connection button on the control panel.
2. Press the “Arm” button on the remote control.
3. The control panel will beep once acknowledging the connection. If the control panel
beeps twice, the detector was already connected.
Specifications
Power supply: DC 3V (CR2025 button battery x1)
Static current: ≤10 uA
Operating current: ≤7 mA
Transmission distance: ≤80 m (in open area)
Radio-frequency:: 433.92MHz (±75KHz)
Housing material: ABS plastic
Operating conditions: -10°C ~ +55°C, ≤80% (non-condensing)
Dimensions: 57 x 31 x 11 mm
