ETQ A16 - Technical Specifications

13
TECHNICAL SPECIFICATIONS
Technical specifications in English units
Model Number A16
Maximum pressure 115 PSI
SCFM @ 40 PSIG 5.2 PSI
SCFM @ 90 PSIG 4.0 PSI
Peak Horsepower 2.5 HP
Voltage 120 Volts
Tank Capacity 4 Gallons
Pump type Oil lubricated piston
Weight 60 lbs
Dimensions 16.5” x 16.5” x 19”
Technical specifications in Metric units
Model Number A16
Maximum pressure 792.9 KPa
Air flow rate @ 276 Kpa 147.2 liters/min
Air flow rate @ 621 Kpa 113.3 liters/min
Peak power 1.87 Kw
Voltage 120 Volts
Tank Capacity 15.14 liters
Pump type Oil lubricated piston
Weight 27.3 Kg
Dimensions 419 x 419 x 483 mm
