18 - Legend 548 Assembly and User Manual
30068-02A
REAR ANGLE PANEL
REAR CROSS MEMBER
Remove the (16) #10x1/2” sheet metal
screws holding the rear angle panel and set
the panel aside.
The rear cross member sits in cradles on
each end and is secured in place with (8)
#10x1/2” sheet metal screws. Remove the
screws and slip the cross member out of the
cradles.
