Legend 548 Assembly and User Manual - 9
30068-02A
On top of the skirt are 4 Phillips fl at head
screws. Remove these screws.
Now tip the skirt forward and lift off the pegs
at the bottom.
As the skirt is removed you will fi nd a cable
attached. This powers the Mood Mode ac-
cent lighting. Disconnect this cable and set
the skirt aside.
