7.5. Lockout mechanism
If the lockout mechanism is pivoted out/extended, the bolt tongue cannot be extended. The lockout mechanism can be
secured with padlocks (see Figure 5).
¨ To pivot out, press the grooved part (only possible with bolt tongue retracted).
1
2
Key:
1
Padlock ∅min. 2mm, ∅max. 10 mm
Notice:
You can t a maximum of 3 locks Ø8mm.
2
Automatically extending, second lockout mechanism
Padlock ∅min. 6mm, ∅max. 10 mm
Figure 5: Lockout mechanism secured with padlock
