25
112657-12-01/15 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB-L0…-AR.-… and MGB-L0…-AP.-…
EN
11.7. Notes on operation with control systems
Please observe the following requirements for connection to safe control systems:
General notes
Ì Use a common power supply for the control system and the connected safety switches.
Ì A pulsed power supply must not be used for UB/UA. Tap the supply voltage directly from the power supply unit. If the
supply voltage is connected to a terminal of a safe control system, this output must provide sufcient electrical current.
Ì The safety outputs (FO1A and FO1B) can be connected to the safe inputs of a control system. Prerequisite: The input
must be suitable for pulsed safety signals (OSSD signals, e.g. from light curtains). The control system must tolerate test
pulses on the input signals. This normally can be set up by parameter assignment in the control system. Observe the
notes of the control system manufacturer. For the pulse duration of your safety switch, please refer to the chapter 13.
Technical data on page 32.
Ì The inputs on an evaluation unit connected must be positive-switching, as the two outputs on the safety switch deliver a
level of +24V in the switched-on state.
AR
Ì Always connect inputs FI1A and FI1B directly to a power supply unit or to outputs FO1A and FO1B of another
EUCHNER AR device (series connection). Pulsed signals must not be present at inputs FI1A and FI1B.
The test pulses are also present when the safety outputs are switched off (only on FO1A). Depending on the
inertia of the connected device (control system, relay, etc.), this can lead to short switching processes.
The inputs on an evaluation unit connected must be positive-switching, as the two outputs on the safety switch deliver a
level of +24V in the switched-on state.
NOTICE
Due to the fact that short circuit monitoring of the safety outputs FO1A/FO1B is performed by the
device itself, the Performance Level in accordance with EN13849 is not reduced if the control system
pulsing is switched off.
Tip!
A detailed example of connecting and setting the parameters of the control system is available for
many devices at www.euchner.de in the area Download Applications MGB. The features of the
respective device are dealt with there in greater detail.
