15
112657-12-01/15 (translation of the original operating instructions)
Operating Instructions Safety Systems
MGB-L0…-AR.-… and MGB-L0…-AP.-…
EN
1
Fit door handle.
2
Insert actuation axis. The locking ring A must be in contact with the escape release B.
3
Tighten setscrew to 2 Nm.
4
Fit protective sleeve.
Protective sleeve
Actuation axis
Example with mounting plates:
58.5
4.2
D
4.2
(10)
55.5
(+4.2 mm per plate)
250
182
Mounting plates
D + 13
3.5
(+4.2 mm per plate)
D + 3.5
1
3
2
4
A
B
Figure 6: Preparing escape release
