21
5.6 UNFOLDING THE BICYCLE CARRIER
Figure 17: Unfolding the bicycle carrier
Figure 18: Folding out the number plate
Figure 19: Engaging the number plate
CLICK!
Figure 20: Opening the wheel stoppers
5.7 MOUNTING THE BICYCLES ONTO THE CARRIER
NOTE
In order to improve the performance of your vehicle, mount
the heaviest bicycle rst. If carrying only one bicycle, this
should be mounted in the rail closest to the boot of the
vehicle.
• Remove all parts not rmly attached to the bicycle, such
as e-bike batteries, the air pump, the cycle bag, the bicycle
case or navigation devices.
BEWARE!
Personal injury or damage to property possible due to
parts coming loose
Improperly tightened parts on the bicycles can become loose
while driving.
