Eureka E51 BASE User Manual

8
Make sure that all the parts indicated in the following list are present before unpacking the machine:
 Squeegee;
 battery box;
 battery jumper L = 25 cm, fitted with terminals and terminal covers;
 battery cable L = 51.5 cm, fitted with connector, terminals and terminal covers;
 battery charger on board the machine;
 two 12 Volt dry charge batteries (optional).
NOTICE: brushes, discs and disc pad holders must be purchased separately.
Follow the instructions below to unpack the machine:
- connect the inclined ramp (position A) to the front part of the pallet, see figure 1;
- tilt the machine slightly and place the wheel lifting plate (position B), see figure 1;
- tilt the machine slightly again and place another wheel lifting plate from the other side of the machine (position C), see
fig. 2;
- remove the machine from the pallet along the inclined ramp (see fig. 3-4).
CAUTION: DO NOT USE A FORKLIFT TO REMOVE THE MACHINE FROM THE PALLET AS IT MAY
CAUSE DAMAGE TO THE MACHINE.
CAUTION: MOUNT THE BATTERIES ONLY AFTER REMOVING THE MACHINE FROM THE PALLET.
UNPACKING
1
2
3
4
