Eureka E51M - Page 13

13
E61 – M610
1. Control panel
2. Tank lid
3. Suction filter lid
4. Suction filter
5. Suction safety filter
6. Filter support
7. Drum of the clean water filter
8. Tank
9. Suction lock float with filter
10. Squeegee inclination adjustment hand-wheel
11. Tank unlock lever
12. Wheels
13. Squeegee pressure adjustment hand-wheel
14. Brush plate lift pedal
15. Recovery tank outlet pipe
16. Instrument panel inclination adjustment hand-wheel
17. Anti-crushing device
18. Level indicator pipe and solution tank outlet drain
19. Tap
20. Battery charger
21. Squeegee lever
22. Battery mobile connector
23. Brake pedal
24. Squeegee
25. Detergent solution filter
26. Solenoid valves
27. Drive gear motor
28. Brushes
29. Vacuum motor
30. Batteries
31. Brush gear motor
32. Splashguard
33. Contactors
34. Fuse holder
35. Drive board
