CLEANING THE DETERGENT SOLUTION FILTER
The machine is fitted with a filter on the duct that
comes from the detergent solution tank.
In theory, the solution located in this tank should
not have any impurities as the buckets or
containers used to fill the solution are supposed
to be clean, in addition there is a filter in the
mouth of the tank that filters the water.
Follow the instructions below to clean the filter:
 Bring the machine into a stop position in a flat
surface area and put on the brake;
 Turn off the machine and
remove the key;
 Close the valve;
OFF
ON
 Unscrew the clear cup manually (see position 2);
 Remove the protective screen (see position 3) and clean it with water together with the cup;
 Put the cup (see position 2) and the protective screen (see position 3) on the fixed part of the filter (see position 4);
make sure the protective screen is fitted correctly into its housing inside the cup and into the support;
 For the V2 TRAC version, open the valve (see position 1) or the lever handle located near the
instrument panel.
OFF
ON
