LEFT SIDE DUST GUARD
SEALING REPLACEMENT
 Remove the key and remove the battery connector
 Remove the left side closure pos. 1
 Remove the steel sheets pos. 2-3
 Remove the sealing pos. 4
 Replace the sealing
 Put everything back together again.

INTERNAL REAR DUST
GUARD SEALING
REPLACEMENT
 Raise the dirt container
 Insert the safety device on the cylinder pos. 10
 Remove the key and remove the battery
connector
 Mark the position of the rubber holder steel
sheet before removing it.
 Remove the dust guard assembly and replace
the sealing pos. 5
 Put everything back together again.
 Remove the piston safety device pos. 10
 Lower the dirt container
REAR DUST GUARD
SEALING REPLACEMENT
 Raise the dirt container
 Insert the safety device on the cylinder pos. 10
 Remove the key and remove the battery
connector
 Remove the rubber block steel sheet pos. 7
 Replace the sealing pos. 6
 Put everything back together again.
 Remove the piston safety device pos. 10
 Lower the dirt container
DIRT CONTAINER DOOR
SEALING REPLACEMENT
 EMPTY THE DIRT CONTAINER AND
KEEP IT RAISED WITH THE DOOR OPEN
 Insert the safety device on the cylinder pos. 10
 Remove the key and remove the battery
connector
 Remove the rubber block steel sheet pos. 9
 Replace the sealing pos. 8
 Put everything back together again
