58
- SCHEMA IMPIANTO: MOTORE AVANZAMENTO - CICALINA E FANALI RETROMARCIA SICUREZZA
SEDILE
- INSTALLATION PLAN FOR: FORWARD MOTOR -REVERSE SPEED LIGHTS AND REVERSE SPEED
ACOUSTIC SIGNAL SEAT SECURITY
- SCHEMA INSTALLATION : MOTEUR AVANCEMENT -SIGNAL ACOUSTIQUE ET FEU DE MARCHE
ARRIERE SECURITE’ SIEGE
-INSTALLIERUNGSPLAN :VORSCHUBMOTOR -AKUSTICHES SIGNAL UND RÜCHWÄRTSGANGLICHT-
SITZSICHERHEIT
- ESQUEMA INSTALLACIÓN : AVANCE MOTOR -SIÑAL ACUSTICA Y FAROS DE MARCHA ATRÁS-
SEGURIDAD ASIENTO
IMPIANTO
ELETTRICO
WIRING
DIAGRAM
ELEKTRISCHE
ANLAGE
INSTALLATION
ELECTRIQUE
INSTALACION
ELECTRICA
CF
Microteleruttore sedile
Quando premuto
contatto chiuso
Seat microswitch
When pressed,
contact
is closed
Sitz Mikroshalter
Wenn man druck,
wird der Kontakt
geschlossen
Microtélérupteurupteur
siege
Si presse’ le contact
est ferme’
Microtélérupteuruptor
asiento. Al estar
pulsado el contacto
está cerrado
H
Polo positivo sotto
chiave
Positive Pole under key
Positive Pol unter
Verschluß
Pôle positif sous clé
Polo positivo bajo llave
L
Diodo 1A
COD. 640132
Diode 1A
COD. 640132
Diode 1A
COD. 640132
Diode 1A
COD. 640132
Diodo 1A
COD. 640132
M
Cicalina allarme
COD. 640175
Acoustic signal
COD. 640175
Akustisches Signal
COD. 640175
Signal acoustique
COD. 640175
Sal acustica
COD. 640175
R
Diodo 3A
COD. 640010
Diode 3A
COD. 640010
Diode 3A
COD. 640010
Diode 3A
COD. 640010
Diodo 3A
COD. 640010
Z
Fusibile 30 A
COD. 640114
Fuse 30 A
COD. 640114
Sicherung 30 A
COD. 640114
Fusible 30 A
COD. 640114
Fusible 30 A
COD. 640114
AH
Batteria 24 V 360 A
COD. 620061
Battery 24 V 360 A
COD. 620061
Batterie 24 V 360 A
COD. 620061
Batterie 24 V 360 A
COD. 620061
Bateria 24 V 360 A
COD. 620061
AI
Interruttore di sicurezza
generale
COD. 660052
Security switch
COD. 660052
Sicherheitschalter
COD. 660052
Interrupteur de securité
COD. 660052
Interruptor de seguridad
COD. 660052
AL
Teleruttore motore
spazzole
COD. 660055
Motor brush
Electromagnetic switch
COD. 660055
Mikroschalter
COD. 660055
Télérupteur moteur
brosses
COD. 660055
Telerupptor motor
cepillos
COD. 660055
AN
Fusibile 100 A
COD. 640040
Fuse 100 A
COD. 640040
Sicherung 100 A
COD. 640040
Fusible 100 A
COD. 640040
Fusible 100 A
COD. 640040
AO
Polo positivo
Positive Pole
Positive Pol
Pôle positif
Polo positivo
AP
Polo negativo
Negative Pole
Negativer Pol
Pôle negatif
Polo negativo
AT
Teleruttore motore
trazione
COD. 660055
Traction motor
connector
Antriebmotor
Mikroschalter
Télérupteur moteur
traction
Teleruptor motor
traccion
BP
Morsettiera
COD. 640199
Terminal board
COD. 640199
Elektrische Verbindung
COD. 640199
Connexion electrique
COD. 640199
Conexión électrica
COD. 640199
