EUROMAG | MC608 | Ed. 10/2018
14 / 60
3 TECHNICAL SPECIFICATIONS MC608
3.1.4 Version MC608B/R (REMOTE)
170,85
111
Ø 125
307
90°
90°
118
125
178,85
102
60 22 70
2" Mounting Pole
247
141,5105,5
Fig. 8 Dimensions MC608B/R (Remote)
3.1.5 Version MC608P (REMOTE)
102,45
10,50 91,95
130
120
183,40
127,50
Mounting clamps Panel mounting plate
Fig. 9 Dimensions MC608P (Remote)
3.1.6 Version MC608I (REMOTE)
303
202
201
288
Fig. 10 Dimensions MC608I (Remote)
