Euromag MC608 Series User Manual

EUROMAG | MC608 | Ed. 10/2018
41 / 60
MC608 CONVERTER PROGRAMMING 5
5.3.2 MENU → COUNTERS
MENU → COUNTERS
• T+
Total positive counter.
• P+
Partial positive counter, resettable to zero.
• T-
Total negative counter.
• P-
Partial negative counter, resettable to zero.
• NET
Net counter: difference between T+ and T-.
Various counters with the MC608 converter are available: two positive (total and partial) and two negative
(total and partial).
Only partial counters can be set to zero.
To set the counters to zero from the MC608 software, access the screen “READ” and press the button
“ZERO” (see 1, Fig. 45) that refers to the partial counter that you want to reset.
The same screen also displays a linear bar (see 2, Fig. 45) which shows the percentage of the
instantaneous ow rate in relation to the full scale capacity set in the converter.
The same screen also displays in a special box (see 3, Fig. 45) of the converter: the current “Date” and
“Time.” In an additional module, external temperature or system operating pressure data are available
2
3
1
Fig. 45
