Euromag MC608 Series User Manual

EUROMAG | MC608 | Ed. 10/2018
18 / 60
3 TECHNICAL SPECIFICATIONS MC608
3.4 ACCURACY
3.4.1 Reference conditions:
• Measuring liquid: water
• Conductivity: >200 µs/cm
• Temperature: 20°C / 68°F
• Pressure: 1 bar / 14,5 psi
• Upstream diameter: ≥ 5 DN
• Downstream diameter: ≥ 3 DN
Model Accuracy class Graphics
MC608A/P/I Class 02 2 ±0,2 % ± 2mm/s Fig. 10
MC608B/R Class 05 5 ±0,5 % ± 5mm/s Fig. 11
MC608 connected to insertion sensor Class 2 2 ±2 % ± 2mm/s Fig. 12
The following accuracy class refers to the measurement conditions during the calibration at the
EUROMAG INTERNATIONAL test benches:
-1,20
-1,00
-0,80
-0,60
-0,40
-0,20
0,00
0,20
0,40
0,60
0,80
1,00
1,20
0,0 0,5 1,0 1,5 2,0 2,5 3,0 3,5 4,0 4,5 5,0 5,5 6,0 6,5 7,0 7,5 8,0 8,5 9,0 9,5 10,0
Error [%]
Speed [m/s]
CLASS 02 2
Fig. 11
