EVCO S.p.A. c-pro 3 micro and c-pro 3 kilo | Hardware manual ver. 1.0 | Code 114CP3UKE104
page 26 of 62
CAN
LED CANbus communication
if it is lit, the device will be configured to communicate via CANbus with another device but the CAN communication
will not have been set up
if it flashes slowly, the CANbus communication will have been set up but it will not be completely correct
if it flashes quickly, the CANbus communication will have been set up and will be correct
if it is out, no CANbus communication will be running
L1
LED auxiliary (not used in c-pro 3 EXP micro / micro+ and in in c-pro 3 EXP kilo / kilo+)
The operation of this LED can be programmed through the development environment UNI-PRO 3
