EV-97 Eurostar SL Microlight Maintenance Manual GEN/EUR/04 Issue 4 43
Appendix 2 - Control Surface Deflection Record
Model:
EV-97 Eurostar
SL Microlight
Registration:
G-
S/N:
Specified
deflection
Actual
deflection
Longitudinal
Elevator upward deflection
25°±1°
Control
Elevator downward deflection
20°±1°
Port aileron upward deflection
20°±1°
Lateral Control
Port aileron downward deflection
15°±1°
Starboard aileron upward deflection
20°±1°
Starboard aileron downward deflection
15°±1°
Rudder
Rudder Port deflection
30°±2°
Control
Rudder Starboard deflection
30°±2°
Port flap deflection in "TAKEOFF" position
15°±2°
Port flap deflection in "LANDING" 1
st
position
30°±3°
Wing
Port flap deflection in "LANDING" 2
nd
position
50°±3°
Flaps
Starboard flap deflection in "TAKEOFF" position
15°±2°
Starboard flap deflection in "LANDING" 1
st
position
30°±3°
Starboard flap deflection in "LANDING" 2
nd
position
50°±3°
Max. difference between port and starboard flap
deflections
2°
Elevator
trim tab
Max. upward trim tab deflection (elevator neutral)
0°±2°
Max. downward trim tab deflection (elevator
neutral)
40°±5°
Neutral trim tab position.
(elevator neutral, trim tab control lever in neutral
position)
15°
Control Surfaces Deflection compliance: YES
Measurements carried out by:
Date:
