Using Your Child Restraint
with the 5-point Harness
• The shoulder harness straps should ALWAYS be
snug against the child and as close as possible, but
NEVER below, the child’s shoulders. The crotch strap
should ALWAYS be snug against the child.
• DO NOT use the 5-point harness if your child weighs
over 21.3 kg (47 lbs) or if the child’s shoulders are
above the highest harness slots. You must use this
child restraint as a belt-positioning booster cushion.
See page 26 for instructions.
Child Requirements
• Weight:
9 – 21.3 kg (20 – 47 lbs)
• Maximum Height:
74 – 114 cm (29 – 45 inches)
Until the upper harness slots
fall below the child’s shoulder
level, OR until the child’s ears
are at the top of the child
restraint seat back.
• Age:
At least one year of age.
• 9 – 21.3 kg (20 – 47 lbs)
AND
• Between 74 and 114 cm (29 and 45 inches).
AND
• At least one year of age.
Use WITH 5-pt Harness
10 11
Place restraint facing forward on vehicle seat. Thread
the vehicle seat belt through the child restraint belt
path . Lift the pad for easier belt routing. Buckle
the vehicle seat belt.
➚
➚
• IMPORTANT •
If the vehicle seat belts are not routed and fastened
correctly, the child restraint may not protect your child
in a crash.
In addition to the lap belt you MUST also use the top
tether strap provided with this restraint if: a) your
vehicle has lap belts that only lock during a sudden
stop or crash (emergency locking retractor); or b) your
vehicle seat belts are forward of the seat crease and
will not hold the child restraint tightly.
Installing Your Child Restraint
Using Seat Belts
1
Place a towel
under the seat to
protect the vehicle
upholstery.
TIP!
TIP!
Using the Child Restraint with the 5-point Harness: 9 – 21.3 kg (20 – 47 lbs) Seat Belt Installation
WARNING
To Next Page
