34
IMPORTANT: Infants may have difficulty breathing
when in an upright seated position. Make sure they
recline enough for their head to lie back comfortably
and safely. Failure to properly recline the child restraint
could increase the child’s risk of serious injury or death.
NOTE: In some vehicles, it may be necessary to place
a tightly rolled towel or small blanket beneath the
front edge of the child restraint to provide enough
recline so that the level line is parallel to the ground.
5. Ensure child restraint is secure.
• For Rear-Facing Installation with Lap Belt,
see pg. 35.
• For Rear-Facing Installation with Lap/
Shoulder Belt, see pg. 36.
Rear-facing Installation with Vehicle
Seat Belts
Shoulder
straps must
be at or just
below child’s
shoulders
1,8 - 18,1 kg (4 - 40 lbs)
43 - 102 cm (17 - 40 in)
MUST be level with
ground with Rear Facing
installations
REAR FACING LINE
Top of head
MUST be 2.5 cm
(1 in.) or more
below top of
headrest or shell
Chest clip
25808432 8/19
Lap Shoulder Belt
LATCH / UAS
Lap Belt
Route shoulder belt
only through lock off.
See user manual for
additional information.
LOCK OFF
REAR FACING
BELT PATH
Shoulder
straps must
be at or just
below child’s
shoulders
1,8 - 18,1 kg (4 - 40 lbs)
43 - 102 cm (17 - 40 in)
MUST be level with
ground with Rear Facing
installations
REAR FACING LINE
Top of head
MUST be 2.5 cm
(1 in.) or more
below top of
headrest or shell
Chest clip
25808432 8/19
Lap Shoulder Belt
LATCH / UAS
Lap Belt
Route shoulder belt
only through lock off.
See user manual for
additional information.
LOCK OFF
REAR FACING
BELT PATH
