15
Make sure the harness
straps are in one of the
three lower strap slots D.
The harness straps should
start at shoulder height or
lower, using the strap slots
closest to your child’s
shoulders E, as shown.
3
DO NOT use the upper harness slots rear-facing. The
harness may not properly restrain the child during a crash.
WARNING
D
E
4
Lap Belt Only
Lap & Shoulder
Belt Combination
G
Pull the seat pad off of the front of the child restraint.
Route the vehicle seat belt F through the rear-facing
belt path G and continue through the opposite
opening of the child restraint. Fasten the vehicle seat
belt, as shown, depending on your type of seat belt.
Note: You MUST use a locking clip with lap/shoulder
seat belt combinations that have a buckle tongue that
slides freely along the belt without locking into place.
(To install a locking clip, refer to p. 30).
G
F
F
To Next Page
