5 For Professional Technical Support call 1-844-241-5521
Pre-Installation(continued)
PACKAGE CONTENTS
NOTE: The adapter is not shown to scale.
Part Description
A Pump
B Adapter (1-1/2 in. MNPT X 1-1/4 in. FNPT)
SPECIFICATIONS
Power supply 115V, 60 HZ., 15 Amp Circuit
Liquid temp. range 32°F to 95°F (0°- 35°C)
Discharge size
1-1/2 in. FNPT or 1-1/4 in. FNPT (with adapter)
Sump basin
Min. 14 in. (356 mm) diameter, 18 in. (457 mm) depth for tethered switch
Min. 10 in. (254 mm) diameter, 14 in. (356 mm) depth for vertical switch
Switch on/off (1001093932,
1001093909, 1001093925)
On: 14.2 in.(361 mm), Off: 5.9 in.(150 mm)
Switch on/off (1001093950) On: 8.4 in.(213 mm), Off: 4 in.(101 mm)
NOTE: Do not reduce size of discharge pipe or hose below 1-1/4 in. diameter. If discharge is too small, pump will overheat
and fail prematurely. This pump is designed for use in a residential sump only. Only pump water with this pump.
Tethered Switch SKU # 1001093932
SKU # 1001093909 SKU # 1001093925
Vertical Switch SKU # 1001093950
