6
Installation
1
Connecting a discharge pi
pe to the
pump
2
Placing the pump in a basi
n
□ Wrap the threads of the 1-1
2 i
n. discharge pipe (1) with
thread sealant tape.
□ Attach the discharge pipe (1) to the discharge of the pump
(2).
□ Place the pump on a hard surfa
ce inside a sump basin.
3
Connecting the check valve
□ Connect the dis
charge pipe (1) to the elbow (2), union (3),
check valve (4), and gate valve (5).
1
2
1
2
4
3
5
