Everdure MURRAY ESEE - Barbecue Carcass Components

STYLE, GRILLED TO PERFECTION
M5 x 12MM SCREW
4 BURNER BARBECUE COMPONENTS
GRILL PLATE
9
7
10
RIGHT HAND
BARBECUE CARCASS
5
3
1
REAR LOUVRE ROD
VAPOURISER
8
SPACER
LEFT HAND
4
6
FAT TRAY
2
BUILT-IN BRACKET
BUILT-IN BRACKET
x1
x1
x1
x1
x2
x8
x1
x1
SOLID PLATE
x1
x4
M5 x 30MM SCREW
16
x8
13
