BRACKETS WITH M5 X 12 SCREWS (PARTS 10). NOTE: THE BRACKETS HAVE THEIR TOP LIPS POINTING AWAY
4. THREAD M5 X 30 SCREWS (PARTS 16) THROUGH 4 HOLES ON EACH BRACKET, THROUGH A SPACER (PART 6)
3. ALIGN THE BRACKETS AT EITHER SIDE OF THE BARBECUE, TO MATCH THE HOLES IN THE BRACKETS TO THE
2. SCREW THE REAR LOUVRE RODS (PARTS 5) TO THE BACK HOLES IN THE LEFT (PART 4) AND RIGHT (PART 3)
1. PLACE BARBECUE (PART 1) ON A RAISED SURFACE (REMOVE FAT TRAY).
FITTING THE BUILT-IN BRACKETS TO THE BARBECUE ASSEMBLY
A
BARBECUE ASSEMBLY
16
16
10
1
3
4
6
6
6
6
10
16
16
5
NUTSERTS IN THE SIDES OF THE BARBECUE. NOTE THERE ARE TWO POSSIBLE HEIGHTS:
A) TOP OF BARBECUE SIDES LEVEL WITH THE TOP OF THE BRACKETS (USE LOWER SETS OF BRACKET HOLES).
B) TOP OF BARBECUE SIDES 20MM ABOVE THE TOP OF THE BRACKETS (USE UPPER SETS OF BRACKET HOLES).
FROM THE BARBECUE.
AND SCREW INTO THE NUTSERTS ON THE BARBECUE SIDE.
15
