2. PLACE THE HOOD ASSEMBLY (PART 11) ON TOP OF THE BARBECUE SO THAT THE TABS IN THE REAR HOOD
SIDES LINE UP WITH THE HOLES ALONG THE INNER EDGES OF THE BARBECUE. TAKE CARE NOT TO DAMAGE
3. PLACE 1 x M5 SCREW THROUGH THE HOLE OF A REAR HOOD SIDE TAB, FIX A FIBRE WASHER, AND LOOSELY FIT
ATTACHING THE HOOD TO THE BARBECUE
1. TO CONNECT THE HOOD, THE FOLLOWING HARDWARE IS NEEDED: FOUR M5 NUTS (PART13),
FOUR M5 x 20 SCREWS (PART 12) AND FOUR FIBRE WASHERS (PART 14).
BARBECUE ASSEMBLY
B
EITHER COMPONENT.
A M5 NUT. REPEAT FOR ALL FOUR HOLES, THEN FULLY TIGHTEN ALL THE NUTS.
4. CHECK THAT THE HOOD OPENS AND CLOSES CORRECTLY BEFORE USE.
11
12
12
13
14
5. THE ESEE SWITCH IS POSITIONED ON THE RIGHT HAND SIDE OF THE FASCIA PANEL. CHECK THE SWITCH
WIRE RUNS ALONG THE "LEG" OF THE CHASSIS AND OUT THE REAR RIGHT SIDE. ADJUST IF NECESSARY.
6. THE HOOD CABLE FOR THE ESEE LIGHTING SYSTEM SHOULD RUN DOWN THE INSIDE OF THE RIGHT HAND
SIDE OF THE HOOD AND OUT THE HOLE IN THE BOTTOM CORNER. CONNECT ONE END OF THE HOOD
7. THE TWO REMAINING WIRE ENDS ARE TO BE CONNECTED TO THE TWO LOOSE ENDS ON THE POWER
ADAPTOR CABLE. WHETHER THIS IS DONE NOW, OR AFTER THE APPLIANCE IS FITTED INTO THE BUILT-IN
A POWER SUPPLY UNTIL THE BARBECUE IS FULLY ASSEMBLED AND ALL CONNECTIONS HAVE BEEN CHECKED.
WIRE TO ONE END OF THE SWITCH WIRE AND PASS ALL WIRES THROUGH THE HOLE IN THE BOTTOM CORNER
OF THE CHASSIS "LEG".
STRUCTURE DEPENDS ON THE INDIVIDUAL DESIGN OF THE STRUCTURE, HOW MUCH GAP IS IN THE RIGHT
HAND CORNER & HOW MUCH CLEARANCE IS UNDERNEATH THE BARBECUE. DO NOT LET ANY BARE CABLES
TOUCH THE CHASSIS OR HOOD. THE POWER ADAPTOR MUST BE FIXED INSIDE THE BUILT-IN STRUCTURE, AWAY
FROM THE HEAT OF THE BARBECUE, THE ELEMENTS AND WATER. DO NOT PLUG THE ELECTRICAL SYSTEM INTO
16
