APPLIANCE DETAILS
MAIN BARBECUE
Gas Type: Propane
N.G
Burner Pressure: 2.75 kPa
0.95
kPa
Injector Diameter: Ø1.10
mm
Ø1.80 mm
Heat Input: 60 MJ/ h
r
60 MJ/ h
r
Note: The size of the injector diameter is stamped on one of the hexagon faces (e.g. ‘180’ for
Ø1.80mm injector).
Front 55mm x Full width of fat tra
y
Rear 100mm x Full width of fat tra
y
Combustion air is admitted at the underside at the front and rear of the combustion chamber.
NOTE: Take care not to block the venting at the rear of the appliance when built-in.
GAS CONNECTIONS
FOR PROPANE CYLINDER CONNECTION
1. To achieve the optimum performance from your Everdure Barbecue, an approved gas cylinder (POL
fitting) of 9kg capacity must be used.
2. Connect the cylinder to the barbecue, via the hose and regulator. Firmly tighten joints, but do not over-
tighten. Take care not to damage the regulator fitting. Check that ALL Barbecue valves are in the Off
position before opening the gas cylinder.
3. Leak test all gas connections.
4. When changing cylinders, disconnect the hose & regulator assembly from the cylinder only (not from the
barbecue manifold).
NOTE: Make sure the gas cylinder is fully protected from the elements. Only one gas cylinder
should be stored inside the cabinet at any one time. Do not fully enclose the cylinder.
FOR NATURAL GAS (NG) CONNECTION
All gas fitting work, service and repairs can only be performed by an authorized person in accordance with
AS5601 and local gas regulations.
1. Fit the NG regulator supplied with the appliance to the barbecue manifold inlet (LHS front, under the
barbecue).
2. The supplied flexible hose assembly should be connected to the other side of the NG regulator.
3. Check that all control knobs are at the Off position. The appliance can now be connected to the NG
supply using the bayonet fitting at the other end of the supplied flexible hose assembly.
4. Set the NG regulator to the correct pressure as stated in the appliance details with two main burners
running at high. Ensure all connections are tight and leak test all gas connections.
5. When disconnecting the appliance from the gas supply, only disconnect the hose from the bayonet outlet
(not at the manifold or regulator). Always cover the exposed fittings so dust or insects cannot enter the
gas system.
NOTE: Only certified components supplied in Everdure conversion kits can be used. The use of unauthorised
gas conversion kits or non-authorised personnel for the gas conversion will void all warranties.
Barbecue only
LENGTH (mm)
W
IDTH (mm)
HEIGHT (mm)
905
590
230
Barbecue, Hood and
Built-in brackets
1005 655 570
