Everlast 1650201 - Assembly Instructions - Part 3; Step 5: Upper Cable Connection; Step 6: Console Assembly Mounting

CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada©2010
8
Step 5.
Connect the Extension Computer Cable (37) with the Upper Computer Cable (36).
37
36
Step 6.
Secure the Console Assembly (39) into the Left & Right Uprights (4,5) with the 6pcs of
5/16”x15m/m Button Head Socket Bolts (94) and 4 pcs of 5/16" x 19 x 1.5T Curved Washers
(95).
94
95
95
95
94
97
39
4
5
