45
ABF 05-10-15
ENGLISH
Alarm High Temperature of Condensation
If the probe condenser is disposal and not damage , when the value of the temperature of the probe condenser is su-
perior to the parameter the display DIS1 visualize the label “Ht”, the buzzer plays.
It stops a possible cycle in progress. The rearmament is automatic when the temperature of the probe condenser is
inferior to the value of the parameter.
Visualization Historical Alarms For HACCP
With label in OFF press for five seconds the key HACCP
to input the printing and visualization of the historical
alarms.
The historical is managed in circular way and can contain and memorized at least ten verified alarms, by type of alarm,
date and hour of when happens, the duration in minutes and record of maximum temperature in the cold room.
The entry of a new alarm in the memory can be visualized making blinking the dot of the right digit of the display DIS1.
To flow the relative information of every single alarm:
Press the key Program
, then press Increase to visualize the following alarm of the list,
press the Decrement
to visualize the preceding alarm.
Press the key ON / OFF
makes return the label in OFF.
The maximum number of minutes visualized is 999, correspondent to 16 hours and 39 minutes. If the alarm remains for
a superior time, are visualized 999 flashing instead of the minutes indication.
In the memory of the alarms, are memorized the following:
• Black out probe cold room
E0
• Black out probe product
E3
• Black out evaporator probe
E1
• Black out condensation probe
E4
• High pressure
HP
• Low pressure
LP
• Thermo compressor
HA
• Open door
d-r
• power failure
PF
• High temperature cold room
AH
• low temperature cold room
AL
• high temp. Condensing
Ht
TERMINAL MANAGEMENT PRINT (OPT.)
The Label is supplied with a door of communication serial RS485.
This door of communication can be used for the connection to a terminal of printing for the unload dates of cycle and
memory diagnosis of alarms. The protocol of communication with the printing terminal, foresees a fixed baud rate to
9600 and bit of odd parity. You advises to verify the configuration of the pint terminal , brought in the relative manual,
before start the connections.
Print Report Of a Cycle dates
The printing dates of a cycle, is automatically activated to the beginning of the Blast/freezing cycle .
The report of print brings the date, the type of selected cycle, the sampling of regular intervals of the temperatures cold
room and product, the cycles of defrosting and possible alarms that are verified during the cycle.
