EVINRUDE ICON REMOTE CONTROL SYSTEM
ICON REMOTE CONTROL SYSTEM TROUBLESHOOTING CHART
ICON Remote Control System Troubleshooting Chart
Note: Items listed in this chart will not result in setting of ICON fault codes.
Observation Possible Cause
Troubleshooting Procedure
ICON system does not
power up.
Remote control is OFF.
I-Command gauges are
OFF.
Battery switch is OFF.
Battery is discharged.
Network power cable 10 Amp
fuse has failed.
Master power/key switch/net-
work 3 Amp fuse has failed.
• Turn battery switch ON.
• Check condition of battery.
• Check 10 Amp fuse. Check network
power cable and connectors for damage.
• Check 3 Amp fuse. Check master
power/key switch power cable, buss
cables, and connectors for damage.
• Disconnect power cable from gateway
module.
Starter motor of outboard
does not operate.
Remote control is ON.
Trim & tilt system operates.
START/STOP switch or har-
ness is faulty.
Engine wiring harness,
starter solenoid, or EMM is
faulty.
Remote control is faulty.
ESM is faulty
• Check START/STOP switch(es) and har-
ness for damage. Swap known good
START/STOP switch(es).
• Check engine wiring harness for dam-
age, swap known good starter solenoid.
• Swap a known good remote control.
• Check ESM, swap known good ESM
Starter motor of outboard
does not operate.
Remote control is ON.
Indicator LEDs are flashing.
Trim & tilt system does not
operate.
Outboard is not connected to
ICON system.
ESM 30 Amp fuse has failed.
• Check buss cables and ICON hubs for
damage.
• Swap known good buss cables or ICON
hub.
• Check 30 Amp fuse. Check power cable,
actuator harness and connectors for
damage.
Outboard(s) will not shut off
with START /STOP switch.
Remote control is ON.
Trim & tilt system operates.
START/STOP switch or har-
ness is faulty
Remote control is faulty.
• Check START/STOP switch(es) and har-
ness for damage.
• Swap a known good remote control.
Outboard(s) will not shut off
with START /STOP switch.
Remote control is ON.
Trim & tilt system does not-
operate.
Outboards must have ICON–
compatible engine manage-
ment software installed in the
Engine Management Module
(EMM).
• If this problem has occurred after install-
ing an ICON conversion kit, make sure
updated engine management software
has been installed in EMM.
Outboard does not shift.
Remote control is ON.
Indicator LEDs display nor-
mally.
Shift actuator is not cali-
brated.
Shift linkage is not installed or
damaged.
Shift actuator arm is loose or
damaged.
• Check shift actuator stroke. Calibrate if
necessary.
• Check shift linkage.
• Check shift actuator arm.
Outboard(s) will not trim/tilt
up and/or down.
Remote Control is OFF.
Master power/key switch
must be in RUN position.
• Turn master power/key switch to RUN
position.
