88
ENGINE MANAGEMENT MODULE (EMM)
INTERNAL SENSORS
INTERNAL SENSORS
Sensor inputs and internal EMM controllers are
used to control outboard operation. Use Evinrude
Diagnostics software to troubleshoot the sensors.
Refer to the EMM Service Code Chart at the
back of this manual for a complete list of all
engine fault codes.
Internal sensors are NOT serviceable. Repro-
gramming or replacement may be required to
resolve internal EMM issues.
EMM Temperature Sensor
Monitors the temperature of the fuel injector driver
circuits.
If the EMM temperature exceeds 176°F (80°C) or
the circuit fails, the EMM:
If EMM temperature exceeds 212°F (100°C) or
the circuit fails, the EMM:
IMPORTANT: The outboard will not restart until
the engine cools below 212°F (100°C)and the
EMM temperature returns to normal. Refer to
SHUTDOWN MODE on p. 94.
If EMM temperature is less than -22°F (-30°C) or
the circuit fails, the EMM:
If sensor reads less than -71°F (-57.4°C) or
greater than 313°F (156°C), a sensor circuit fault
is detected and the EMM:
55 V Circuit Sensor
Monitors the EMM’s 55 V alternator circuit.
If system voltage exceeds 57 volts, the EMM:
If system voltage is below 45 volts with outboard
running 500 to 1000 RPM or is below 52 volts with
outboard running above 1000 RPM, the EMM:
12 V Circuit Sensor
Monitors the EMM’s 12 V alternator circuit.
If battery voltage exceeds 15.5 volts, the EMM:
If battery voltage is below 12 volts with outboard
running 500 to 2000 RPM OR is below 12.5 volts
with outboard running above 2000 RPM, the
EMM:
Activates S.A.F.E.
Stores service code 25
EMM LED 4: ON (Running)
Engine Monitor TEMP display: ON
Activates SHUTDOWN
Stores service code 29
EMM LED 4: FLASHING
Engine Monitor TEMP display: FLASHING
Stores service code 24
EMM LED 3: OFF (Cranking)
EMM LED 3: ON (Running)
Stores service code 23
EMM LED 3: OFF (Cranking)
EMM LED 3: ON (Running)
Activates S.A.F.E.
Stores service code 18
EMM LED 1: ON (Running)
Engine Monitor CHECK ENGINE display: ON
Activates S.A.F.E.
Stores service code 17
EMM LED 1: ON (Running)
Engine Monitor CHECK ENGINE display: ON
Stores service code 27
EMM LED 1: ON (Running)
Engine Monitor LOW BATTERY display: ON
Stores service code 26
EMM LED 1: ON (Running)
Engine Monitor LOW BATTERY display: ON
