42
ENGINE OPERATION
6
○：
Transom angle settings
○：
Tilt release position
a
b
!
●
Do not put hand or finger in between
outboard motor body and clamp
bracket when adjusting trim angle to
prevent injury in case the outboard
motor body falls.
●
Unsuitable trim position can cause
loss of control of boat.
When testing a trim position, run
boat slow initially to see if it can be
controlled safely.
P type
①
Operate the Power Tilt switch and
tilt the outboard motor up. (The
Main Switch must be "ON".)
The outboard motor can also be
tilted up using the switch provided
under the bottom cowl. (The Main
Switch need not be turned "ON" in
this case.)
TP type
①
Operate the Power Tilt switch and
tilt the outboard motor up.
UP
DN
