Evo 425T - Motor Base; Bottle Rack

www.evofitness.net.au
19
3 LEFT UPRIGHT 1 40 FLAT FOOT PAD 4
4 RIGHT UPRIGHT 1 41 BLACK CUSHION PAD 2
5 MOTOR BASE 1 42
MIDDLE-EMPTY INNER
TUBE CAP
4
6 ADJUST BRACKET 1 43 PLASTIC BEARING 2
7 SUPPORTING BRACKET 1 44 SLIDE BLOCK 2
8 COMPUTER SUPPORT 1 45 DRIVING BELT 1
9 LABEL 2 46 SAFETY LOCK 1
10 Regular Washer 8 47 LEFT END CAP 1
11 COMPUTER COVER 1 48 RIGHT END CAP 1
12 COMPUTER PANEL 1 49 TRANSFORMER 1
13 BOTTLE RACK 1 50
LOWER CONTROL
BOARD
1
14 BRACKET 1 51 HAND END CAP 2
15 LEFT MOTOR LIGHT COVER 1 52 FOAM 2
16 RIGHT MOTOR LIGHT COVER 1 53 PLASTIC FIXED BLOCK 1
17 MOTOR COVER 1 54 KNOB 1
18 LEFT END CAP L 1 55 WHEEL END CAP 4
19 LEFT END CAP R 1 56 FRONT ROLLER 1
20 SMALL END CAP L 1 57 BOTTOM ROLLER 1
21 SMALL END CAP R 1 58 OILINESS AXIS SET 2
22 RIGHT END CAP L 1 59 AIR PRESSURE BAR 2
23 RIGHT END CAP R 1 60 5#wrench 5mm 1
24 MOTOR COVER FRONT CAP 1 61 6#wrench 6mm 1
25 RUNNING MAT 1 62 Wrench
S=13，14，15
1
26 SIDE RAIL 2 63 “Z “inductor connector 1
27 BOTTOM BOARD 1 64 SLIDE RAIL AXIS CORE 1
28 BOTTOM END CAP 1 65 LIMIT DIGIT CORE AXIS 1
29 MOVING WHEEL 4 66 SPRING WASHER 8 6
30 ADJUST WHEEL 2 67 SCREW M8*30 4
31 RUNNING BOARD 1 68 BOLT M8*40 1
32 LEFT END CAP 1 69 BOLT M8*65 2
33 RIGHT END CAP 1 70 BOLT M8*25 6
34 END CAP 2 71 BOLT
M8*30*20
2
35
RING PROTECTING WIRE
PLUG
2 72 BOLT
M8*42*20
5
36
CUSHION PAD 1
RED 4 73 BOLT
M8*48*20
4
37
CUSHION PAD 2
BLUE 2 74 BOLT
M8*50*20
2
75 BOLT M10*25 8 113
AC SINGLE WIRE 1
76 BOLT
M10*45*20
1 114
SINGLE WIRE 1 1
77 BOLT
M10*62*20
1 115
AC SINGLE WIRE 1
78 BOLT M8*30 1 116
BOLT M8*16 2
79 BOLT M6*22 14
80 BOLT M5*6 7
