Evo Centric 20E Electric - EDGE to EDGE Temperature Mode

15
HOT SURFACE
T
O
EDGE EDGE
100
o
F
SET
TEMPERATURE
Centric 20E Control Panel
Basic Feature
HOT SURFACE
T
O
EDGE EDGE
325
o
F
ACTUAL
TEMPERATURE
Pressing the blue UP arrow when the unit is powered ON increases the temperature as indicated
in the display window. Each subsequent press of the UP arrow increases the SET temperature
by +25F°(+14°C).
Pressing the blue DOWN arrow decreases the temperature as indicated in the display window.
Each subsequent press of the DOWN arrow decreases the set temperature by -25F° (-14°C).
When the unit is turned on, the window momentarily displays the system check screen and then
the EDGE to EDGE temperature mode screen appears.
ON
EDGE to EDGE Temperature Mode
EDGE to EDGE temperature mode is the default mode automatically selected
when unit is powered ON.
Pressing the MODE button for one second displays the ACTUAL temperature of the cooking
surface in EDGE to EDGE mode (+/ - 25°F or 14°C)
MODE
