6
Unloading From Travel Case
Remove Unit From Optional Travel Case
1 - POSITION CASE VERTICALLY WITH WHEELS AND FRONT POST AGAINST THE FLOOR - Allow case to rest
on fl at surface in a vertical position with three latches on each side unobstructed.
USE CAUTION - Make sure the travel case in resting on a level surface.
2 - REMOVE CASE TOP AND LIFT UNIT UPWARD FROM CASE - Release latches, remove case top, and set top
case aside. Left unit directly upward and position unit on a level tabletop cooking area. Additional storage for
cooking utensils and cleaning supplies is located within the right side of the case.
USE CAUTION - The Centric 20E unit is heavy and it may be necessary to have an assistant
help lift the unit from the case.
Front
Post
Rear
Wheels
Case Latches
Three Each Side
STEP #1
Spatulas,
Cleaning Kit
Storage
Release Latches
Remove Case Top
STEP #2
To Next Page
