Evo Centric 20E Electric - Electrical Schematic

17
12V
L1 L2
TC
1
TC
2
TC
3
LCD DISPLAY
TEMP CONTROL UNIT
Inner Heater
Element
DO NOT CONNECT TO AN ELECTRICAL SYSTEM OPERATING AT LESS THAN 120 VOLTS AND NOT MORE THAN 120 VOLTS WITH A MINIMUM 20 AMPS WITH A GROUNDED CIRCUIT Evo, Incorporated 8140 SW Nimbus Ave., Bldg 5 Beaverton, Oregon 97008 USA
MODEL: CENTRIC 20E 20 AMP ELECTRIC CONTROL / ELECTRIC COOKTOP 120V / 20 AMP / 1-PHASE / 3-WIRE / 50-60HZ
FOR SUPPLY CONNECTIONS USE COPPER WIRE ONLY SUITABLE FOR AT LEAST 90°C (194°F). #12 AWG OR LARGER.
120V
L2 L1
L1
Outer Heater
Element
L2
Solid State
Relay
Solid State
Relay
L2
L1
R2
R1
Snap Disk Thermostat Snap Disk Thermostat
L1
R1
R2
Electrical Schematic
