8
Clearance Dimensions
Clearances To Combustible Surfaces
8” (203mm)
Clearance To Left Sidewall From Cooking Surface
32” (812mm)
Clearance To Ceiling From Cooking Surface
8” (203mm)
Clearance To Right Sidewall From Cooking Surface
3/4” (19mm)
Air Space Clearance Required Under Unit
The Evo Centric may be installed to back, side, and front combustible surfaces with a zero-clearance (0” or 0mm)
tolerance to the outside of the stainless steel chassis. The top of the cooking surface requires 32” (813mm) to
combustible surfaces. The underside of the unit requires 3/4” (19mm) air space clearance for proper ventilation and
operation.
8” (203mm)
Clearance To Backwall From Cooking Surface
