Evolution Controls EVO/ECM-Modbus - Register 15 - Group Address 1; Register 16 - Group Address 2

©Evolution
Controls Inc.
10-Sept-2020
EVO/™ECM-Modbus RTU Series 2 Page 48
Application Guide
©2020 All Rights Reserved
Evolution Controls Inc.
San Diego, CA USA
Coil/Flag
#
Function
Value/Range
Detail
Read
Multiple
Register
Write
Multiple
Register
Read
Single
Register
Write
Single
Register
Register 6
Motor 1 RPM
Low Byte
Dynamic
integer 0-1500
Updates every 833
milliseconds
Y
Y
High Byte
Register 7
Motor 2 RPM
Low Byte
Dynamic
integer 0-1500
Updates every 833
milliseconds
Y
Y
High Byte
Register 8
Motor 3 RPM
Low Byte
Dynamic
integer 0-1500
Updates every 833
milliseconds
Y
Y
High Byte
Register 9
Motor 4 RPM
Low Byte
Dynamic
integer 0-1500
Updates every 833
milliseconds
Y
Y
High Byte
Register 10
Motor 1 Flow Index
Low Byte
EEPROM
Integer 0-100
1-100% Flow Index
0 = Motor Off
Y
Y
High Byte
Not Used, reads as 0, write only 0's
Register 11
Motor 2 Flow Index
Low Byte
EEPROM
Integer 0-100
1-100% Flow Index
0 = Motor Off
Y
Y
High Byte
Not Used, reads as 0, write only 0's
Register 12
Motor 3 Flow Index
Low Byte
EEPROM
Integer 0-100
1-100% Flow Index
0 = Motor Off
Y
Y
High Byte
Not Used, reads as 0, write only 0's
Register 13
Motor 4 Flow Index
Low Byte
EEPROM
Integer 0-100
1-100% Flow Index
0 = Motor Off
Y
Y
High Byte
Not Used, reads as 0, write only 0's
