Enclosure
These drawings detail the minimum inside floor and face dimensions for a suitable enclosure.
1.20”
2.20”
3.58”
4.25”
1.00”
0.20"
0.61”
0.90”
0.12”
0.38”
3.36”
Inside Face
3.58”
0.90”
2.75”
2.20”
0.38”
Ø 0.25”
0.21”
2.34”
Inside Floor
