Evolution Digital
EVO-SUP-DMS2002HD-U-001-v1r0 Page 51
6.5 MSO Info
The MSO Info screens provide information about what will show on-screen when service to the DTA is interrupted
or the DTA is not activated. Table 15 defines the parameters displayed in the MSO Info screens.
Table 15 MSO Info Screen Parameters
Parameter
Description
Service Interruption Message
The current service interruption message
that will be displayed on-screen by the
DTA.
Activation Support Message
The current activation support message
that will be displayed on-screen by the
DTA.
Figure 29 and Figure 30 show examples of the MSO Info screens as presented on the DTA.
Figure 29 Diagnostic Menu – MSO Info, Screen 1
