Evolution Digital
EVO-SUP-DMS2002HD-U-001-v1r0 Page 66
Table 22 HDMI Screen Parameters
Parameter
Description
Device Connected
Set to Yes if the HDMI cable is currently
connected to a TV and is in use.
HDCP Enabled
Set to yes if HDCP copy protection is
enabled.
Output Format
The current output format (resolution).
Aspect Ratio
The current output aspect ratio (16:9 or
4:3)
EDID Data
Under the EDID Data entry there is a list
of the four combinations of supported
output formats. To the right of each entry
will be either a Yes or a No depending on
whether or not the connected TV supports
each output.
Figure 39 shows an example of the HDMI screen as presented on the DTA.
