Evolution Digital
EVO-SUP-DMS2002HD-U-001-v1r0 Page 61
VCM
Count of the number of VCM tables
received by the DTA.
STT
Count of the number of STT tables
received by the DTA.
Ops
Count of the number of Operation
messages received by the DTA.
Config
Count of the number of Configuration
messages received by the DTA.
EAS
Count of the number of EAS messages
received by the DTA.
EM
Count of the number of EMMs received
by the DTA.
CAT
Count of the number of CAT PIDs
received by the DTA.
CAT Err
Count of the number of errored CAT
PIDs received.
CVT
Count of the number of CVT tables
received by the DTA.
Last Addressable Timestamp
Date and time for when the last
addressable message was received by the
DTA.
In this screen, if you press the number “0”, all counters will be reset to “0”. Anytime the DTA is reset, all counters return to 0.
Figure 37 shows an example of the Received Messages screen as presented on the DTA.
