Evolution Digital
EVO-SUP-DMS2002HD-U-001-v1r0 Page 71
Last Command
The hex value of the last remote control
command received by the DTA.
Signal Strength
The RF signal strength (in dBm) between
the DTA and the remote control. It can
take the following values:
Poor (< -85 dBm)
Average (> -85 dBm and < -75 dBm)
Good (> -75 dBm)
Link Quality
The link quality between the DTA and
the remote control. It can take the
following values:
Poor (< 80)
Average (< 80 and > 140)
Good (> 140)
Battery Level
The voltage level reported by the remote
control battery.
Instruction Screen Visible
(True or False) indicates whether the RF
pairing instruction screen is visible.
Line of Sight
(Yes or No) indicates if a remote control
is in sight of the DTA.
Just Booted
This value is set to Yes when the DTA
was booted within the last 30 minutes.
After 30 minutes the flag is set to No.
Empty Pairing Table
Set to Yes if there is a problem pairing
