www.evolutionfury.com
12
LH VIEW OF FURY 6 MITRE SAW CONFIGURATION
1. CUTTING HANDLE
2. ROTARY TABLE
3. RETRACTABLE LOWER BLADE GUARD
4. BLADE
5. BEVEL LOCKING LEVER
(Back of the machine)
6. MITRE ANGLE LOCKING SCREW
7. MITRE ANGLE SCALE
8. FENCE
9. HOLD DOWN CLAMP
10. STABILISING ARMS (X2 Back of machine)
11. CUTTING HEAD RELEASE LEVER
12. TABLE HEIGHT ADJUSTING SCREW
9
5
6
7
8
3
4
2
1
10
12
11
