TO CONFIGURE THE FURY6 FOR USE AS
A MITRE SAW
WARNING: Only carry out this procedure
with the machine disconnected from the
power source.
Caution: The Fury6 has many built in safety
features and safety interlocks. It is important
that the following instructions, and those
found on the label attached to the machine
table are read, understood and acted
upon. Failure to carry out the configuration
procedure could result in damage to the
machine and/or injury to the operator.
• Loosenthetableheightadjustment
screw. (Fig.4)
• Raisethetabletoptoitsupmostposition
and tighten the height adjustment screw.
(Fig. 5)
• SlightlypushdownontheCuttingHead
Handle.
• PullouttheCuttingHeadLatchingPin
and allow the Cutting Head to rise to its
upmost position. (Fig. 6)
• RemovetheAuxiliaryLowerBladeGuard
and store safely for future use.
The Fury6 is now ready to use as a
Mitre Saw. (Fig. 7)
Fig. 7
Fig. 4
Fig. 5
Fig. 6
